Trek
Trek Fuel EX 9.8
Trek Fuel EX 9.8
Couldn't load pickup availability
Adapt, rip, repeat
Only you can define your perfect trail bike; that's why Fuel is available in three adjustability-packed configurations. Get do-it-all capability with EX, go pop-happy with MX or charge through it all with LX.
Adjustable leverage rate
Want more bottom-out resistance without giving up small-bump sensitivity? Flip the chip in the lower shock mount for a more progressive leverage rate.
Zero stack integrated headset
With a ZS standard headset, you've got loads of options for aftermarket upgrades, including angle adjust or anodised colours.
Storage and accessory mounts
Stash ride essentials with in-frame storage on all Fuel models, both carbon and alloy. Plus, top tube accessory mounts let you load up even more.
Fresh frame design
The Fuel's new frame gives you loads of room for long dropper posts, bigger shocks, frame bags and more.
Active Braking Pivot
Active Braking Pivot allows our engineers to tune how the suspension reacts to acceleration and braking forces independently. That means you get more confident control when you need it most.
Technical Specifications
Components
| GRIPS | Trek Line Elite, lock-on |
| HANDLEBAR | Race Face Turbine, alloy, 35 mm, 40 mm rise, 780 mm width |
| HEADSET | FSA Orbit, sealed cartridge bearing, 1-1/8'' top, 1.5'' bottom, 1.5 crown |
| SADDLE | Verse Short Comp, steel rails, 145 mm width |
| SEATPOST | Size: S Bontrager Line Dropper, 150mm travel, MaxFlow, internal routing, 34.9 mm, 410 mm length Size: M Bontrager Line Dropper, 170 mm travel, MaxFlow, internal routing, 34.9 mm, 450 mm length Size: L, XL, XXL Bontrager Line Dropper, 200 mm travel, MaxFlow, internal routing, 34.9 mm, 515 mm length |
| STEM | Bontrager Elite, 35 mm, 0-degree, 45 mm length |
Drivetrain
| BOTTOM BRACKET | Shimano BB-MT501 BSA |
| BRAKES | Shimano XT M8220 4-piston hydraulic disc |
| BRAKES ROTOR | Front, Shimano RT86, 6-bolt, 203 mm. Rear, Shimano RT86, 6-bolt, 180 mm |
| CASSETTE | Shimano XT M8200, 10-51, 12-speed |
| CHAIN | Shimano Ultegra/XT M8100 |
| CRANKSET | Shimano XT 8200, 30T, 55 mm chain-line |
| REAR DERAILLEUR | Shimano XT M8250, long cage |
| SHIFTERS | Shimano XT Di2 M8250, 12-speed |
Frame
| FORK | Fox Factory 36, Float EVOL air spring, GRIP X2 damper, 44mm offset, Boost 110, 15mm Kabolt X axle, 150mm travel |
| FRAME | OCLV Mountain Carbon, internal storage, ZS headset, adjustable leverage rate, guided internal routing, interchangeable alloy rocker link, interchangeable lower shock mount, downtube guard, shuttle guard, BSA 73, ISCG 05, ABP, UDH, Boost148, adaptable travel 145 mm-160 mm |
| FRONT TRAVEL | 150MM |
| REAR SHOCK | Fox Factory Float X, 205mm x 60mm |
| REAR TRAVEL | 145MM |
Wheels
| FRONT TYRE | Size: S, M, L, XL, XXL Maxxis Minion DHF, tubeless ready, 3C, EXO+ casing, MAXXGRIP, folding bead, 29x2.5" |
| FRONT WHEEL | Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost110, 15 mm thru-axle, 29" |
| REAR TYRE | Size: S Maxxis Minion DHR II, tubeless ready, 3C, EXO+ casing, MAXXTERRA, folding bead, 27.5x2.5" Size: M, L, XL, XXL Maxxis Minion DHR II, tubeless ready, 3C, EXO+ casing, MAXXTERRA, folding bead, 29x2.5" |
| REAR WHEEL | Size: S Bontrager Line Comp 30, Tubeless Ready, Rapid Drive 108, 6-bolt, Shimano Micro Spline freehub, Boost148, 12 mm thru-axle, 27.5" Size: M, L, XL Bontrager Line Comp 30, Tubeless Ready, Rapid Drive 108, 6-bolt, Shimano Micro Spline freehub, Boost148, 12 mm thru-axle, 29" |
