Trek
Trek Fuel EX 9.8 EA90 Xlxlarge
Trek Fuel EX 9.8 EA90 Xlxlarge
Couldn't load pickup availability
Technical Specifications:
- Primary Battery Type: Li-Ion 300mAh 7.4 Volt
- Rim Size: 29INCH
- Frame Material: Carbon
- Frame: OCLV Mountain Carbon, internal storage, ZS headset, adjustable leverage rate, guided internal routing, interchangeable alloy rocker link, interchangeable lower shock mount, downtube guard, shuttle guard, BSA 73, ISCG 05, ABP, UDH, Boost148, adaptable travel 145 mm-160 mm
- Fork: RockShox Lyrik Ultimate, DebonAir+ w/ ButterCups, Charger 3.1 RC damper, tapered steerer, 44 mm offset, Boost110, 15 mm Maxle Stealth, 150 mm travel
- Fork Travel (Max): 170 mm
- Shock: RockShox Deluxe Ultimate RC2T, 205 mm x 60 mm
- Wheel (front): Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost110, 15 mm thru-axle, 29INCH
- Wheel (rear): Bontrager Line Comp 30, Tubeless-Ready, Rapid Drive 108, 6-bolt, SRAM XD freehub, Boost148, 12 mm thru axle, 29''
- Tires: Maxxis Minion DHF, tubeless-ready, 3C, EXO+ casing, MAXXGRIP, folding bead, 29x2.5'' // Maxxis Minion DHR II, tubeless-ready, 3C, EXO+ casing, MAXXTERRA, folding bead, 29x2.5''
- Tire size (max): Frame: 29x2.50INCH, Fork: See manufacturer
- Tire Size: 29x2.50INCH
- Tire Part: Bontrager TLR sealant, 180 ml/6 oz
- Rim Strip: Bontrager TLR
- Skewer (rear): Bontrager Switch thru axle, removable lever
- Shifters: SRAM Eagle 90, 12-speed
- Rear Derailleur: SRAM Eagle 90, T-Type
- Crank: SRAM Eagle 90, DUB, 30T steel, T-Type, 55 mm chainline, 170 mm length
- Bottom Bracket: SRAM DUB MTB Wide, 73 m, BSA threaded
- Cassette: SRAM Eagle XS-1275, T-Type, 10-52, 12-speed
- Chain: SRAM GX Eagle, T-Type, 12-speed
- Chainring (Max): Max: 34T (oval – 32T) Min: 30T (oval – 32T)
- Brake: SRAM Maven Bronze 4-piston hydraulic disc // SRAM Maven Bronze 4-piston hydraulic disc
- Rotor size: Max brake rotor sizes – Frame: 203 mm, min 180 mm, Fork: see fork manufacturer
- Brake Rotor: SRAM HS2, 6-bolt, 180mm // SRAM HS2, 6-bolt, 200mm
- Saddle: Verse Short Pro, carbon rails, 145 mm width
- Seatpost: Bontrager Line Dropper, 200 mm travel, MaxFlow, internal routing, 34.9 mm, 515 mm length
- Handlebar: Race Face ERA, carbon, 35 mm, 27.5 mm rise, 800 mm width
- Stem: Bontrager Elite, 35 mm, 0-degree, 45 mm length
- Grips: Trek Line Elite, lock-on
- Weight: M - 15.38 kg / 33.91 lbs (with TLR sealant, no tubes)
- Weight Limit: This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
- Brake Brand: SRAM
- Shifter Brand: SRAM
- Rear Suspension Brand: RockShox
- Fork Brand: RockShox
Detailed Specs
Adapt, rip, repeat
Only you can define your perfect trail bike – that's why Fuel is available in three adjustability-packed configurations. Get do-it-all capability with EX, go pop-happy with MX or charge through it all with LX.
Adjustable leverage rate
Want more bottom-out resistance without giving up small-bump sensitivity? Flip the chip in the lower shock mount for a more progressive leverage rate.
Zero stack integrated headset
With a ZS standard headset, you've got loads of options for aftermarket upgrades, including angle adjust or anodised colours.
Storage and accessory mounts
Stash ride essentials with in-frame storage on all Fuel models – both carbon and alloy. Plus, top tube accessory mounts let you load up even more.
Fresh frame design
The Fuel's new frame gives you loads of room for long dropper posts, bigger shocks, frame bags and more.
Active Braking Pivot
Active Braking Pivot allows our engineers to tune how the suspension reacts to acceleration and braking forces independently. That means you get more confident control when you need it most.
